High-Precision Power Bank Housing Injection Molding

The manufacturing of this precision circular mounting bracket relies on strictly controlled cycles within advanced single-color injection molding machines. To achieve the high structural integrity required for precision equipment, raw engineering polymers (such as PC or reinforced ABS) are meticulously dried to eliminate moisture before being heated to precise melt temperatures. The molten resin is injected at high pressure to completely fill the asymmetrical geometry, seamlessly flowing from the main circular ring into the extended mounting arm. The single-color molding process is optimized with specific holding pressures and cooling times to ensure the material solidifies uniformly, preventing any dimensional warping that could compromise the alignment of the final assembled device.

Our DFM approach for this power bank housing is optimized for the efficiency and accuracy of single-color mold tooling:

• Uniform Wall Thickness: The housing is designed with balanced wall thickness throughout, which promotes uniform cooling and structural consistency, eliminating the risk of warping.
• Internal Ribbing & Bosses: The interior is reinforced with a strategic grid of stiffening ribs and precision-molded screw/snap-fit bosses, providing a rigid mounting platform for the internal battery cell and the charging PCB.
• Integrated Light Apertures: The LED charge indicator slots are formed directly during the primary injection cycle, ensuring clean, burr-free edges that meet high-end consumer product standards.
• Modular Mating Fit: The two-piece enclosure is engineered with tight assembly tolerances to ensure a seamless fit, providing protection against dust and debris while maintaining a sleek, tamper-resistant exterior.

Each production batch undergoes a comprehensive validation process:

• Dimensional Accuracy: Use of Coordinate Measuring Machines (CMM) to verify the alignment of PCB mounting points and snap-fit tolerances for secure assembly.
• Visual Surface Inspection: Total elimination of flow lines, sink marks, or flash, ensuring the final consumer product aesthetic is flawless.
• Assembly Load Testing: Ensuring the housing snap-fit features are robust and can withstand repeated assembly/disassembly without structural fatigue.

• Consumer Electronics: Standardized housing for portable power banks, backup batteries, and fast-charging mobile accessories.
• Portable Power Solutions: Protective enclosures for various small-scale energy storage devices used in home, office, and travel environments.
• Custom Electronic Prototyping: A reliable chassis for small-scale projects requiring high-quality plastic protection and a professional look.

Since 1997, We operated from a 6,000 ㎡ factory in Ningbo, enjoying excellent transport links to nearby cities. We focus on developing lighting products, thermoelectric cooling modules, and custom-made plastic and metal molds. With state-of-the-art workshops, advanced production lines, ISO 9001 & SMETA certifications, and patented technologies, we deliver robust monthly output. Our dedicated team ensures superior quality, efficient processes, and timely global shipment.

Injection Workshop

Raw Material Warehouse

Hardware Workshop

Assembly Workshop

Laboratory

Office Area



The workshop is divided into specialized functional zones to support efficient production and streamline workflow organization.

Our factory owns advanced equipment to maximize precision and operational efficiency.
